DB Technologies DVA MS12 Active Bass Reflex Flyable Subwoofer

DVA MS12 is the flyable subwoofer which comes with the DVA Mini series.
Especially designed to fit perfectly with an M2M and M2S array, the MS12 is equipped with a single 12″ woofer in a bass reflex enclosure, acting as a perfect low-end extension module for DVA Mini systems.

DB Technologies DVA MS12 Features:

Acoustical data

• Frequency Response [-6dB]: 45 – 140 Hz
• Frequency Response [-10dB]: 40 – 165 Hz
• Max SPL: 131 dB
• LF: 12″
• Voice Coil LF: 3″
• Directivity: Omnidirectional

Amplifier

• Amp Technology: Digipro G3
• Amp Class: Class D
• Power Supply: 700W SMPS with PSU Auto-range (110V~ and 220V~)
• LF Amp: 700 W RMS (1400 W Peak)
• Cooling: Convection

Processor

• Controller: DSP 56 bit
• AD/DA Converter: 24 bit/48 kHz
• Controls: X-Over frequency selection, Phase selection (0 or 180), Outputs mode selection (Link/X-over), Mini-USB type B port (service data)
• Limiter: Dual active, RMS/Peak, Thermal
• Crossover Frequency LF-HF: 90 – 120 Hz
• LF X-over out slope: 24 dB/Octave
